Industrial Use Hydraulic Grab Bucket Clamshell Grab For Water Conservancy Project
Brief Introduction
Industrial Use Hydraulic Grab Bucket Clamshell Grab include four-petal grabs, six-petal grabs, eight-petal grabs, and there are five types, which are single rope, double rope, four rope, motor, and hydraulic.
Clamshell grab is suitable for materials with harsh environment, irregular and difficult handling materials. Such as garbage, ore, scrap steel, aluminum ingots, limestone, gravel and other materials for loading and unloading and transfer. The grab has been widely used in dumps, scrap yards, ports, mines, railways. (Motor grab cannot be launched in water)
Technical Parameters
Two rope, four rope multi-lobed grab technical parameter table (LS two rope grab, L4 four rope grab)
| Model |
Grab volume m³ |
Grab type |
Material ratio t/m³ |
Grab capacity T |
Crane capacity T |
Grab weight T |
Grab height m |
| LS1 |
0.5 |
heavy |
1.2-2 |
1.3 |
3 |
1.4 |
1800 |
| LS2 |
0.75 |
heavy |
1.2-2 |
1.9 |
5 |
2.1 |
2310 |
| LS3 |
1 |
heavy |
1.2-2 |
2.2 |
5 |
2.6 |
2620 |
| LS4 |
1.5 |
middle |
1.6 |
2.4 |
5 |
2.6 |
2965 |
| LS5 |
1.5 |
heavy |
3 |
4.5 |
10 |
4.8 |
2965 |
| LS6 |
2 |
heavy |
1.2-2 |
3.2 |
10 |
4.9 |
3100 |
| LS7 |
3 |
middle |
1.6 |
4.8 |
10 |
4.7 |
3700 |
| LS8 |
5 |
light |
1 |
5 |
10 |
4.5 |
4900 |
| L4.1 |
0.5 |
heavy |
1.2-2 |
1.3 |
3 |
1.4 |
1800 |
| L4.2 |
0.75 |
heavy |
1.2-2 |
1.9 |
5 |
2.1 |
2310 |
| L4.3 |
1 |
heavy |
1.2-2 |
2.2 |
5 |
2.6 |
2620 |
| L4.4 |
1.5 |
middle |
1.6 |
2.4 |
5 |
2.6 |
2965 |
| L4.5 |
1.5 |
heavy |
3 |
4.5 |
10 |
4.8 |
2965 |
| L4.6 |
2 |
heavy |
1.2-2 |
3.2 |
10 |
4.9 |
3100 |
| L4.7 |
3 |
middle |
1.6 |
4.8 |
10 |
4.7 |
3700 |
| L4.8 |
5 |
light |
1 |
5 |
10 |
4.5 |
4400 |
Technical parameters of single rope multi-lobed grab
| Model |
Grab volume m³ |
Grab type |
Material ratio t/m³ |
Grab capacity T |
Crane capacity T |
Grab weight T |
Grab height m |
| LX1 |
0.5 |
heavy |
2.6 |
1.3 |
3 |
1.1 |
1800 |
| LX2 |
0.75 |
heavy |
2.6 |
1.95 |
5 |
1.5 |
2100 |
| LX3 |
1 |
heavy |
2.6 |
2.6 |
5 |
2.3 |
2540 |
| LX4 |
1.5 |
middle |
1.2-2 |
2.1 |
5 |
2.6 |
2965 |
Technical parameter table of electric multiple flap grab
| Model |
Grab volume m³ |
Grab type |
Material ratio t/m³ |
Grab capacity T |
Crane capacity T |
Grab weight T |
Grab height m |
| LD1 |
0.5 |
heavy |
2 |
1 |
3 |
1.5 |
2300 |
| LD2 |
0.75 |
heavy |
2 |
1.5 |
5 |
2.1 |
2600 |
| LD3 |
1 |
heavy |
2 |
2 |
5 |
2.45 |
2800 |
| LD4 |
1.5 |
middle |
1.6 |
1.6 |
5 |
2.5 |
3200 |
| LD5 |
3 |
middle |
1.6 |
1.6 |
10 |
4.6 |
3800 |
Main Features
1) Simple structure ,easy installation and maintainance.
2) Adopting advanced world famous brand components in electric parts and operation parts.
3) with the great abrasive resistance, high strength and can grab the material very well.
4) Running in a high authorization and internationalization,no pollution.
5) Widely used in Wharf, steel mills, power plants, ships, etc.
Product Tags:
|
|
Material Handling 50T Clamshell Hydraulic Grab Bucket Images
|
